| Data link layer protocol and technology | LAN | MAC address learning amount limit; static Mac configuration; black hole MAC |
| Dynamic and static ARP; proxy ARP; free ARP | ||
| Ethernet; Ethernet II; VLAN; 802.3x; 802.1p; 802.1Q; 802.3ad | ||
| Q-in-Q and flexible Q-in-Q; VLAN mapping | ||
| STP/RSTP/MST; GVRP; Super VLAN; PVLAN; Voice VLAN; Monitor link; BPDU TUNNEL; PPPOE+ | ||
| Multi to one port mirroring; multi to multiport mirroring; RSPAN | ||
| Security | Security features | IPv4/v6 ACL; AAA; 802.1X; RADIUS; TACACS+; SSH; port security; user classification; port isolation; UNI/NNI isolation; DHCP snooping; DAI; ARP check; IP source guard; CPU protection |
| Attack protection | URPF; LAND attack; SYN Flood attack; Smurf attack; Ping Flood attack; TearDrop attack; Ping of Death attack | |
| Network protocol | Routing protocol | Static router; ECMP; Network load balancing |
| Multicast protocol | IGMP PROXY; IGMP filter; MLD v1/v2; IGMP Snooping; MLD v1/v2 Snooping | |
| IP application | DHCP Client; DNS; Ping; FTP Server; FTP Client; IP Accounting; UDP Helper; NTP | |
| IPv6 | IPv6 basic function: IPv6 ND, IPv6 PMTU, IPv6 ACL, DS-Lite, IPv4/v6 Dual Stack | |
| QoS | Traffic classification | Based on port/MAC address/IP address/IP priority/DSCP priority/TCP or UDP port number/ protocol type etc. |
| Traffic policing | CAR | |
| Congestion management | SP; WRR; SP+WRR | |
| Congestion avoidance | RED; WRED | |
| Virtualization | Virtualization technology | Stacking, up to 8 devices |
| Management | Network management | Console port; HTTP; Telnet; SSH management; SNMP v1/v2/v3; RMON 1/2/3/9; SYSLOG; DDMI |
| Line management | VCT; UDLD | |
| Traffic analysis | sFlow traffic analysis | |
| OAM | SLA | Including network delay/network jitter/packet loss rate test |
| Reliability | Link reliability | ERPS(G.8032) ring network protocol |
| Data Center Features | Netconf; M-LAG |
| IEC 60068-2-6 vibration: | 1 mm, 2 Hz-13.2 Hz, 90 min.; 0.7 g, 13.2 Hz-100 Hz, 90 min.; 3.5 mm, 3 Hz-9 Hz, 10 cycles, 1 octave/min.; 1 g, 9 Hz-150 Hz, 10 cycles, 1 octave/min |
| IEC 60068-2-27 shock: | 15 g, 11 ms duration, 18 shocks |
| EN 61000-4-2 electrostatic discharge (ESD): | 4 kV contact discharge, 8 kV air discharge |
| EN 61000-4-3 electromagnetic field: | 10V/m (80-1000MHz), 3V/m (1000-6000MHz) |
| EN 61000-4-4 fast transients (burst): | 2 kV power line, 1 kV data line |
| EN 61000-4-5 surge voltage: | power line: 2 kV (line/earth), 1 kV (line/line), 1 kV data line |
| EN 61000-4-6 Conducted Immunity: | 10 V (150 kHz-80 MHz) |
| EN 61000-4-8 power freq magnetic field: | 30A/m |
| EN 61000-4-11 voltagedips,shortinterrupt: | 0%(20ms), 40%(300ms), 70%(500ms), 0%(5s) |
| EN 55032: | EN 55032 Class A |
| EN 61000-3-2: | EN 61000-3-2 Class A |
| EN 61000-3-3: | EN 61000-3-3 |
| FCC CFR47 Part 15: | FCC 47CFR Part 15, Class A |
| FCC: | CE/FCC Compliant |
| China Network Access Certificate: | Compliant |
| CCC: | Compliant |
| RoHS Compliant: | RoHS ((EU) 2015/863) and RoHS (GB/T26572-2011) compliant |
| Accessories to Order Separately: | Network Management Industrial HiVision, SFP |
| Scope of delivery: | "Device, console cable, installation package, "*Power cord does not included in the package" |
| Update and Revision: | Revision Number: 0.93 Revision Date: 02-03-2025 |
