TEMPERATURE SENSOR
Measuring range: -30 to +80 °C
Accuracy: ±0.4 °C
Resolution: 0.1 °C

HUMIDITY SENSOR
Measuring range: 0 to 100 % RH
Accuracy: ±2.5 % RH from 5 to 95 % at 23 °C
Resolution: 0.1% RH

DEW POINT
Measuring range: -60 to +80 °C
Accuracy: ±1.5 °C at ambient temperature T 30 %
Resolution: 0.1 °C

ATMOSPHERIC PRESSURE SENSOR SENSOR
Measuring range: 600 to 1100 hPa
Accuracy: ±1.3 hPa at 23 °C from 800 to 1100 hPa
Resolution: 0.1 hPa

GENERAL TECHNICAL DATA
Operating temperature: -30 to +80 °C
Channels: internal sensor of temperature, humidity sensor and atmospheric pressure
Counted values: dew point, absolute humidity, specific humidity, mixing ratio, specific enthalpy
Output: RS485
Range of humidity sensor temperature compensation: all temperature range
Available temperature units: degrees Celsius, degrees Fahrenheit
Communication protocol: ModBus RTU, ARION, Advantech ADAM
Power: 9-30 Vdc
Protection class: IP54 electronics; IP40 sensors
Dimensions: 88,5 x 170 x 39,5 mm; stem length 75 mm
Weight: approx. 150 g
Warranty: 3 years
